3.1.2 Rear Panel Overview
Control Definitions
1. Trigger pads
2. Encoders
3. [Control Bank/Reset] button
4. [Pad Bank] button
5. [Full Level] button
6. [Program Select] button
7. [Note Repeat Configuration] button
8. [Note Repeat] button
9. [Kensington Lock] button
10. Full Sized USB connector
3.2 Setup
If you intend to connect your ORCA PAD16 to a computer or mobile devices , please read sections 3.2 to 3.4 first.
3.2.1 Minimum System Requirements
If you are using your ORCA PAD16 with a computer, the following minimum system requirements apply:
Windows Mac OS
i3 1.2GHz or higher Macintosh i3*1.2GHz/P4*1.2GHz or higher
(CPU requirement may be higher for laptops) (CPU requirement may be higher for laptops)
1G RAM OS X 10.3.9 with 1G RAM,
Direct X 9.0b or higher OS X 10.4.2 or greater with 1G RAM
Windows XP (SP2) or higher *G3/G4 accelerator cards are not supported.
(Windows 98, Me, NT or 2000 not supported)
WORLDE suggests you also check the minimum system requirements for your software, as they may be greater than the above.
USB hubs are not supported. WORLDE suggests that you connect directly to one of your computer’s built in USB ports.
3.2.2 Using The ORCA PAD16 With Your Software
When installed, the ORCA PAD16 appears as a simple MIDI device with one input port and one output port. You should select the listed
USB MIDI Controller input port as the MIDI input device in your software. Once this is set, your software should be able to receive notes
and controller data from the ORCA PAD16.
The port name is defined as WORLDE when connecting to USB port.
It will appear as WORLDE in the Device Manager.
