11
EN
COMPONENT LISTS
1. ONOFF SWITCH
2. SPINDLE LOCK BUTTON
3. WHEEL GUARD
4. WHEEL
5. FLANGE
6. SCREW
7. HEX KEY M4
8. 6.4 MM BUTTERFLYTYPE BLADE ARBOR ADAPTER
Not all the accessories illustrated or described are included in standard
delivery.
TECHNICAL DATA
Type Designation WX741 WX741.X (741-designation of machinery,
representative of sander and grinder)
WX741 WX741.X*
Rated Voltage
20 V
Max**
Motor type Brushless
No load speed 14000-24000 rpm
Blade size
50 mm
38 mm
Blade bore
10 mm (only for 50 mm blade)
6.4 mm Butterfly-type with adapter (only for 38 mm blade)
Spindle thread M4
Machine weight (bare tool) 212 g
* X=1-99, A-Z, M1-M9 there are only used for different customers, there are no safe
relevant changes between these models.
**Voltage measured without workload. Initial battery voltage reaches maximum of
20 volts. Nominal voltage is 18 volts.
