76
2-in-1 Cordless Li-ion Grass Trimmer/Edger EN
1. REAR HANDLE
2. AUXILIARY HANDLE
3. TELESCOPIC SHAFT
4. LOCKING COLLAR
5. AUXILIARY HANDLE LOCKING LEVER
6. SAFETY GUARD
7. FLOWER GUARD
8. EDGER WHEEL
9. LINE CUTTER
10. BATTERY PACK
11. TRIMMER HEAD COVER (See Fig M2)
12. CAP RELEASE LATCH (See Fig M2)
13. SPOOL (See Fig M2)
14. TRIMMER HEAD (See Fig M2)
15. EYELET (See Fig M2)
16. LINE FEED BUTTON (See Fig M1)
17. CHARGER (See Fig D)
18. CHARGED INDICATOR LIGHT (GREEN) (See Fig D)
19. CHARGING INDICATOR LIGHT (RED) (See Fig D)
20. WALL MOUNT BRACKET, TOOL (See Fig N)
