2-in-1 Cordless Li-ion Grass Trimmer/Edger EN
1. REAR HANDLE
2. AUXILIARY HANDLE
3. TELESCOPIC SHAFT
4. LOCKING COLLAR
5. AUXILIARY HANDLE LOCKING LEVER
6. SAFETY GUARD
7. FLOWER GUARD
8. EDGER WHEEL
9. LINE CUTTER
10. BATTERY PACK
11. TRIMMER HEAD COVER (See Fig K2)
12. CAP RELEASE LATCH (See Fig K2)
13. SPOOL (See Fig K2)
14. TRIMMER HEAD (See Fig K2)
15. EYELET (See Fig K2)
16. LINE FEED BUTTON (See Fig K1)
17. WALL MOUNT BRACKET, TOOL (See Fig L)
18. LOWER SHAFT COUPLING (See Fig F1)
19. UPPER SHAFT (See Fig F1)
20. MOTOR HOUSING OF TRIMMER HEAD (See Fig H1)
