13
2-in-1 Grass Trimmer/Edger
EN
handle with one hand and Auxiliary Handle with the
other hand. Keep unit below waist level. Work only
from your right to your left to ensure debris is thrown
away from you. Without bending over, keep line
near and parallel to the ground (perpendicular when
edging) and not crowded into material being cut.
WARNING!
Make sure that line is fed out before operation.
Make sure motor is up to full speed before trimming
or edging.
WARNING!
Only use 1.65mm diameter cutting line. Other
sizes of line will not feed properly and will result in
improper cutting head function or can cause serious
injury. Do not use other material such as wire,
string, rope, etc. Wire can break off during cutting
and become a dangerous projectile that can cause
serious injury.
Action Figure
Assembly
Assembling the Main Handle
Note: Make sure that the handle is
firmly locked in place. Do not try to
remove these pieces after connecting.
See Fig. A
Assembling the Safety Guard
WARNING! Make Sure the
Safety Switch is Locked Off
to Prevent Accidental Starting.
See Fig. B1, B2
Removing/Installing Battery Pack
Note: When removing the battery
pack, hold it firmly to avoid
potential accidents.
See Fig. C1, C2
Charging Battery Pack
More details can be found in
charger’s manual.
See Fig. C3
Operation
Safety ON/OFF Switch
WARNING! The cutting
head continues to rotate after
the trimmer has been switched off;
wait until it has completely stopped
then lay down the tool.
See Fig. D
Trimming See Fig. E
Using Flower Guard See Fig. F1, F2
Edging
WARNING! Always remove
the battery pack before
adjusting the trimming head position.
Note: The trimmer head will only
rotate in one direction.
See Fig. G1- G3
Manually Feeding the Line See Fig. H
Removing the Cap See Fig. I1, I2
Replacing the Trimmer Line and
Spool
See Fig. J
Manually Winding the Line See Fig. K1-K4
WORKING HINTS
1. AUTOMATIC LINE FEED SYSTEM
When initially switching on the trimmer, a small
length of line is fed out. A ‘clattering’ noise will be
heard when the lines hit the Line Cutter. DO NOT
BE ALARMED. This is quite normal. After about 5
seconds the line will be cut to the correct length and
the noise will reduce as the motor gains full speed.
If the noise of the line being cut can’t be heard,
more line will need to be fed out. To feed more line,
it is first necessary to allow the trimmer to stop
completely; it must come to a complete rest, then
restart, allowing the motor to reach full speed.
Repeat above until you hear the line hitting against
the Line Cutter.
2. MANUALLY FEEDING THE LINE (SEE FIG. H)
Press and release manual line feed button (13), whilst
gently pull out the lines until the lines reaches the
line cutter.
If the line extends past the line cutter, too much line
has been fed out.
If too much line is fed out, remove the cutting head
cover and rotate the spool anti-clockwise until the
line is at the desired length.
STORING YOUR GRASS
TRIMMER
Always remove the battery pack from
your trimmer after use.
Store in a dry place where the trimmer and battery
can be protected from damage.
MAINTENANCE
Always remove the battery pack from
your trimmer after use.
Always check the product prior to being used for any
damage.
Never operate your product if it is damaged.
Your power tool requires no additional lubrication
or maintenance. There are no user serviceable parts
in your power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean with
a dry cloth. Always store your power tool in a dry
place. Keep the motor ventilation slots clean. Keep all
working controls free of dust.
