Hedge Trimmer WG212E
OPERATING INSTRUCTIONS
WARNING! Do not use the product without
attaching the guard and front handle.
INTENDED USE
This machine is intended to be used domestically for
cutting and trimming hedges and bushes.
1. ASSEMBLY OF THE GUARD (See Fig. A)
Insert the Safety Guard (5) into the slot as illustrated in
Fig A;
Use two screws to fix the guard securely; making sure it
is securely attached.
2. FRONT HANDLE ASSEMBLY
The Front Handle (4) must be assembled before
use:
1) Attach the Front Handle to the housing. Push the
small button (a) inside first. Make sure the protruding
marks on the Front Handle fit perfectly into the
matching indentation on the housing. (See Fig. B & C)
2) Insert and tighten the 4 screws.
3) Check whether handle is firmly secured, if not
retighten the screws.
Make sure the handle is securely attached in
place.
3. MAINS SUPPLY CABLE STRAIN RELIEF
(See Fig .D)
An extension cord retainer is supplied to reduce strain
on the power cord. To use this feature, form a loop at the
end of the extension cable and bring this through the
opening at the bottom of the Extension Cord Retainer,
then wrap the end of the loop around the hook and pull
to tighten.
A
B
C
D
