Cordless Pruning Saw WG324E WG324E.X
K
pA
3 dB(A)
Wear ear protection.
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined
according to EN 62841:
Vibration emission value: a
h
< 2.5 m/s
2
Uncertainty K = 1.5 m/s
The declared vibration total value and the declared
noise emission value have been measured in
accordance with a standard test method and may be
used for comparing one tool with another.
The declared vibration total value and the declared
noise emission value may also be used in a
preliminary assessment of exposure.
WARNING: The vibration and noise emissions
during actual use of the power tool can differ from
the declared value depending on the ways in which the
tool is used especially what kind of workpiece is
processed dependant on the following examples and
other variations on how the tool is used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well maintained.
The use of the correct accessory for the tool and
ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any anti
vibration and noise accessories are used.
And the tool is being used as intended by its design
and these instructions.
This tool may cause hand-arm vibration
syndrome if its use is not adequately managed.
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing the
job. This may significantly reduce the exposure level
over the total working period.
Helping to minimise your vibration and noise exposure
risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration and noise accessories.
Plan your work schedule to spread any high vibration
tool use across a number of days.
INTENDED USE
• The mini pruning saw is intended for cutting only
wood and branches up to a diameter corresponding
to the length of the pruning saw guide bar.
• The mini pruning saw must be used at ground level
or from a suitable platform that is completely stable
and secure.
• During using, the mini pruning saw should be held
in both hands, right hand on the Grip Area and left
hand on the Secondary Grip Area.
• The mini pruning saw is intended for outdoor use
only.
• The mini pruning saw is not intended for any other
use.
• Mounting of parts on the mini pruning saw is
authorized only for original or manufacturer-
approved spare parts (chain guides or saw chains for
example) as well as for authorized chain guide / saw
chain combinations as indicated in the manual.
• The user is responsible for any accident resulting
from improper use or unauthorized modification of
the mini pruning saw.
ASSEMBLY
WARNING! Do not install the battery pack
before it has been completely assembled.
Always use gloves when handling the chain.
MOUNTING THE SAW CHAIN
1. Unpack all parts carefully. Remove the Housing-
Cover by turning the Housing-Cover Knob in a
counterclockwise direction. (See Fig. A1)
2. Place the pruning saw on a solid, level surface.
3. Use only genuine Worx Chains or those
recommended for Guide Bar.
4. Slide the Chain in the slot around the Guide Bar.
Ensure the Chain is in correct running direction by
comparing it to the chain icon on the Guide Bar, or
referring to the chain direction symbol found on
the saw body. (See Fig. A2)
5. Fit the Chain onto the Drive Sprocket, so that the
Fastening Bar Bolt and the Bar Locating Tab on
the Bar Pad fit into the keyway of the opening on
the Guide Bar. (See Fig. B1, B2)
6. Assure all parts are seated properly. Make
sure the drive links are fully seated in the Drive
Sprocket (See Fig. C1), avoiding a kink as shown
in Fig. C2. If kink occurs, pick up the Chain at the
Guide Bar just ahead of the kink and then pull the
kink out.
NOTE: Chain should rotate freely and be free of
kinks.
7. Fit the Chain Cover and tighten the Chain Cover by
turning the Housing-Cover Knob clockwise until it
