All-in-One Blower/Vac/Mulcher EN
OPERATION
INTENDED USE:
The blower & Vac is intended for residential use only. Use the blower outdoors to move or
vacuum yard debris as needed.
ASSEMBLY AND OPERATION
ACTION FIGURE
Blow mode
Assembling the Blower/ Vacumm Tube See Fig. A & B1 & B2
Attaching the Extension Cord
See Fig. C1 & C2
Starting & Stopping See Fig. D
Using the Blower See Fig. E1 & E2
Adjusting the Blowing Speed See Fig. F
Vaccumming
Attaching the Leaf Collection Bag See Fig. G1 & G2 & G3
Attaching the Extension Cord
See Fig. C1 & C2
Starting & Stopping See Fig. D
Using the Vacuum See Fig. H1 & H2
Emptying the Leaf Collection Bag See Fig. I1 & I2 & I3
Removing Clogged Debris from the Impeller(no tool included) See Fig. J1 & J2
STORAGE
Store the Blower/Vacuum and extension cord indoors, in a cool dry location, out of reach of
children and animals.
TROUBLE SHOOTING
Problems Possible Causes Corrective Action
The Blower/Vac does
not operate.
The Blower/Vacuum Tube is not
attached to the Motor Housing.
Attach the Blower/ Vacuum
Tube to the Motor Housing.
Power cord is not connected to the
power source.
Connect the power cord to a
power source.
The Blower/Vac
jammed or clogged.
Debris blocking in the Impeller
Remove clogged debris from
the Impeller.
Debris blocking in the Blower/
Vacuum Tube or the connection of the
Leaf Collection Bag.
Remove clogged debris from
the Blower /Vacuum Tube or
the connection of the Leaf
Collection Bag.
