8
3-in-1 Cordless Lawn Mower EN
1. OPERATING BAIL
2. SAFETY KEY
3. INTELLICUT DIAL
4. BATTERY PACK
5. FRONT CASTER WHEEL CONTROL BUTTON
6. FRONT CASTER WHEEL
7. FRONT CASTER WHEEL CUTTING HEIGHT ADJUSTMENT LEVER
8. WASHOUT PORT
9. REAR WHEEL
10. REAR WHEEL CUTTING HEIGHT ADJUSTMENT LEVER
11. SAFETY FLAP
12. HANDLE BAR
13. GRASS COLLECTION BAG
14. HANDLE RELEASE KNOB
15. BATTERY POWER INDICATOR
16. MULCHING PLUG
17. BLADE BOLT (See Fig. O1)
18. BLADE (See Fig. O1)
19. FAN (See Fig. O1)
20. SPACER (See Fig. O1)
21. SIDE-DISCHARGE COVER
22. SIDE-DISCHARGE CHUTE
Not all the accessories illustrated or described are included in standard delivery.
