TO SHARPEN BLADE IN A VISE (See Fig. N)
1. Be sure the switch lever is released, the
blade has stopped and the safety key
removed before removing the blade.
2.
Remove blade from mower. See instructions
for removing and attaching blade.
3. Secure blade N-1 in a vise N-2.
4. Wear safety glasses and be careful not to
cut yourself.
5. Carefully file the cutting edges of
the blade with a fine tooth file N-3 or
sharpening stone.
6. Check balance of blade. See instructions
for blade balancing.
7. Replace blade on mower and tighten
securely. Refer to instructions below.
BLADE BALANCING (S
ee
Fig. O)
Check balance of blade by placing center
hole in blade O-1 over a nail or screwdriver
shank O-2, clamped horizontally in a vise O-3.
If either end of the blade rotates downward,
file that end. Blade is properly balanced when
neither end drops.
BLADE MAINTENANCE (See Fig. P1, P2)
Renew your metal blade after 50 hours
mowing or 2 years, whichever is the sooner-
regardless of condition.
Follow these procedures to remove and
replace the blade. You will need garden
gloves (not provided) and a spanner wrench
(not provided) to remove the blade. Hold the
blade (20) and unscrew the blade bolt (19)
counter-clockwise using a spanner wrench,
and then remove blade.
To re-assemble, position the blade (20) with
the cutting edges towards the ground. Then
securely tighten the blade bolt (19).
STORAGE (See Fig. M1, M2)
Stop the mower and always remove the
safety key. Clean the exterior of the machine
thoroughly using a soft brush and cloth. Do
not use water, solvents or polishes. Remove
all grass and debris, especially from the
ventilation slots.
Turn the machine on its side and clean the
blade area. If grass cuttings are compacted
in the blade area, remove with a wooden or
plastic implement.
Store the machine in a dry place. Do not place
other objects on top of the machine.
To aid storage, release the handle knob, and fold
the upper handle as shown in Fig. M1 & M2 .
TROUBLE SHOOTING
Problem Solution
1. Mower doesn’t run
when switch lever is
activated.
A. Check to make sure safety key has been installed and is fully
seated and that button on switch housing is being completely
pushed.
B. Release Switch Lever to turn mower off. Remove safety key,
turn mower over and check that blade is free to turn. If not free,
return to an authorized servicer. Blade should turn freely.
C. Has battery been fully charged? Plug in charger and wait for
green light to come on.
2. Motor stops while
mowing.
A. Release Switch Lever to turn mower off. Remove safety key, turn
mower over and check that blade is free to turn. If not free, return to
an authorized servicer. Blade should turn freely.
B. Raise cutting height of wheels to highest position and start
mower.
C. Has battery been fully charged? Plug in charger and wait for green
light to come on.
D. Avoid overloading the mower. Slow down the cutting pace by
pushing mower slower or raise the cut height. Or both.
