Operating instructions
Note: Before using the tool, read the instruction book
carefully.
SAFETY ON/OFF SWITCH (See A)
The switch is locked off to prevent accidental starting. Depress the
lock off button (2) then on/off switch (1) and release lock off button
(2). The machine is working now. To switch off just release the on/off
switch.
CUTTING DEPTH ADJUSTMENT (See B)
Smaller cutting depth of 0-1mm (Max. 2.0mm) is best for most
surface planing or rebating. Rotate the cutting depth adjustment(4)
to set the required cutting depth on the scale ,Scale graduation =
0.125mm. The clockwise rotation increases the planing depth; the
counterclockwise rotation reduces the planing depth.
ADJUST DUST EXTRACTION AND CHIP EJECTION
Dust extraction can be adjusted to the right or left side by manually.
Rotating one end of the dust extraction (5) until it stops (See C).
The arrowhead on the dust extraction indicates the dust extraction
direction.
Note: Due to the size and material of some wood shavings e.g.
wet or hard wood it is possible for the dust extraction to become
blocked. Remove the plug from the mains power supply, then
using a wooden stick clear the blocked dust extraction.
BASEPLATE STAND
Uplift the rear of the planer, the baseplate stand (6) can make the
machine to be set down directly and protect the cutting blades
from any damage and the blades from damaging the surface (See
D). When planing, the stand will be pushed away by the end of the
wood. Always check the stand is free to move on the base plate (See
E).
BLA
DE FITTING AND CHANGING
Warning: Remove power cord from the socket before
carrying out any adjustments or changing blades.
The
blade has two cutting edges, which can be reversed .When
replacing or reversing the plane blades, the guide groove guarantees
constant height adjustment.
Note: Dull and worn blade cannot be reground and must be
replaced.
Remove the plug from the mains socket. Using the Socket spanner
(19) provided loosen the 3 bolts approximately 1/2 rotation counter-
clockwise (See F.1).Holding the blade clamp (7) in position, using
a piece of wood slides the blade (8) out of the blade clamp (7) to
remove the blade from the blade clamp (See F.2).
Note: there is no need to remove the blade clamp (7) as this
can change the factory settings for cutting blade height control.
Bef
ore reinserting a new or reverse blade, always clean both the
blade and the blade seat if dirty. Slide the blade into the blade clamp
in the correct orientation. Check the blade is equal with the clamp.
When tightening the screws(10) ensure the correct tightening
sequence(
1
,
2
,
3
). Before starting, rotate by hand to check the roller
is free to rotate.
Rotate the blade head by a further 180
o
and repeat the procedure
disassembling the second plane blade.
