20V Multi-Function
Inflator
WX092
WX092.X
COMPONENT LIST
1. INCREASE AIR PRESSURE BUTTON
2. STARTSTOP BUTTON
3. DECREASE AIR PRESSURE BUTTON
4. POWER BUTTON
5. WORKLIGHT
6. ADAPTER HOLDER
7. HOSE
8. BATTERY PACK
9. HOSE CLAMP
10. AIR CHUCK
11. AIR CHUCK CLAMP
12. PRESTA VALVE ADAPTER SEE FIGURE E2
13. SPORT BALL NEEDLESEE FIGURE E3
14. TAPERED ADAPTER SEE FIGURE E4
15. WORKLIGHT BUTTON SEE FIGURE F
*Not all the accessories illustrated or described are
included in standard delivery
TECHNICAL DATA
WX092 WX092.X***
Rated voltage 20 V Max**
Inflation efficiency
(0 to 2.4 bar for
215/55R17 tires)
4 mins
Working pressure
10 bar(150 psi) Max
8 bar (120 psi) 2.5 mins/7.5 mins
Weight (Bare tool) 0.95 kg
** Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal voltage
is 18 volts.
*** X=1-999, A-Z, M1-M9 there are only used for different
customers, there are no safe relevant changes between
these models
SUGGESTED BATTERIES AND
CHARGERS
Category Model Capacity
20V Battery
WA3550 1.5 Ah
WA3550.1 1.5 Ah
WA3551 2.0 Ah
WA3551.1 2.0 Ah
WA3553 4.0 Ah
20V Charger
WA3760 0.4 A
WA3869 2.0 A
WA3880 2.0 A
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to the
accessory packaging for further details. Store personnel
can assist you and offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction
book carefully.
INTENDED USE
This product is a multifunctional device, combining
inflators, tire pressure monitor, lighting, SOS warning
four functions in one.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Checking the Battery Pack Condition
NOTE Fig. A1 only applies for the
battery pack with battery indicator
light.
See Fig .A1
Removing the Battery Pack See Fig. A2
Charging the Battery Pack See Fig. A3,A4
Installing the Battery Pack See Fig. A5
OPERATION
To Next Page
