Worx WX543 Quick Start Guide

Cordless Jigsaw EN
10
Blade Removal
NOTE: Hold the blade with one hand
when remove the blade.
See Fig.
B2
Vacuum Adapter Installation
See Fig.
B3
Vacuum Adapter Removal
NOTE: Press and hold the projection
on the bottom of the vacuum adapter
before pulling it out of the machine.
See Fig.
B4
OPERATION
Pendulum Function See Fig. C
Safety On/Off Switch
NOTE: For safety reasons the On/
Off switch of the machine cannot be
locked; it must remain pressed during
the entire operation.
Increasing or reducing the pressure
on the On/Off switch enables stepless
stroke-rate control of the switched-on
machine.
See Fig. D
Straight Cut and Curve Cut
See Fig.
E1, E2
Bevel Cut
NOTE: Remove the vacuum adapter
before adjust the base plate.
NOTE: Rotate the base plate to the
desired position according to the
scale. Ensure the blade is engaged
between the blade positioning wheel.
See Fig.
F, G
Plunge Cut See Fig. H
WORKING HINTS FOR YOUR
JIGSAW
If your power tool becomes too hot, please run your
jigsaw no load for 2-3 minutes to cool the motor.
Avoid prolonged usage at very low speeds.
Always use a blade suited to the material and material
thickness to be cut. For tight curves it is best to use
a narrow saw blade. When sawing metal or similar
materials, apply coolant/lubricant alongside the
cutting line.
Always ensure the workpiece is firmly held or clamped
to prevent movement. Any movement of the material
may affect the quality of the cut. The blade cuts on the
upward stroke and may chip the uppermost. Ensure
your uppermost surface is a non-visible surface when
your work is finished.
For easier control, use low speed to start cutting and
then increase to correct speed.
In order to avoid operation malfunctions, do not saw
gypsum board from below or overhead.
The guide roller should occasionally be checked for
wear and lubricated with a drop of oil. If it is worn, it
must be replaced.
MAINTENANCE
Remove the battery pack from the tool before
carrying out any adjustment, servicing or
maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free
of dust. Occasionally you may see sparks through the
ventilation slots. This is normal and will not damage
your power tool.
FOR BATTERY TOOLS
The ambient temperature range for tool and battery
use and storage is 0
o
C -45
o
C.
The recommended ambient temperature range for the
charging system during charging is 0
o
C -40
o
C.
TROUBLESHOOTING
Symptom
Possible
Causes
Possible
Solution
The tool
suddenly
stops
during
operation.
Overload
Battery
temperature too
high
Low battery
capacity
Relieve the load
on the machine
immediately and
allow cooling
for approx. 30
seconds by
running the
machine on no-
load.
Charge the
battery pack.
ENVIRONMENTAL
PROTECTION
Disposal
The machine, its accessories and
packaging materials should be sorted
for environmentally friendly recycling.
The plastic components are labeled for categorized
recycling.

Worx WX543 Specifications

General

Handle type	Top handle
Product color	Black, Orange
Orbital action	-
Adjustable speed	Yes
Idle stroke rate (max)	- spm
Power source	Battery
AC input voltage	18 V

Weight and Dimensions

Weight	- g
