Worx WX543 User Manual

Cordless Jigsaw EN
1110
1. LOCK-OFF BUTTON
2. ON/OFF SWITCH
3. BATTERY PACK RELEASE BUTTON *
4. BATTERY PACK *
5. PENDULUM ACTION CONTROL LEVER
6. VACUUM ADAPTER
7. BASE PLATE
8. ROLLER GUIDE
9. SAW BLADE
10. CONTACT PROTECTOR
11. TOOL-FREE BLADE HOLDER
12. LED LIGHT
13. HEX KEY
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WX543 WX543.2 WX543.9
(540-559-designation of machinery,
representative of Jig Saw)
WX543
WX543.2
WX543.9
Voltage 20V Max*
No load speed 0-2600/min
Stroke length 24mm
Cutting
capacity
Wood 80mm
Aluminum 18mm
Steel 8mm
Bevel capacity ±45°
Weight 2.1kg 1.7kg
* Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.
ACCESSORIES
WX543
WX543.2 WX543.9
Charger (WA3860)
/ 1 /
Charger (WA3880)
1 / /
Battery pack
(WA3551.1)
1 1 /
Wood cutting
blade
1 1 1
Vacuum adapter
1 1 1
Hex key
1 1 1
10pcs Jigsaw
blade kit
(WA8105)
/ 1 /
We recommend that you purchase your accessories
listed in the above list from the same store that sold
you the tool. Refer to the accessory packaging for
further details. Store personnel can assist you and
offer advice.
NOISE INFORMATION
A weighted sound pressure L
pA
=88.3dB(A)
A weighted sound power L
wA
=99.3dB(A)
K
pA
&K
wA
3 dB(A)
Wear ear protection
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined
according to EN 62841:
cutting boards
Vibration emission value
a
h
,B=9.134 m/s
2
Uncertainty K = 1.5 m/s²
cutting steel
metal
Vibration emission value a
h
,M
= 9.105 m/s
2
Uncertainty K = 1.5 m/s²
The declared vibration total value and the declared
noise emission value have been measured in
accordance with a standard test method and may be

Worx WX543 Specifications

General

Handle type	Top handle
Product color	Black, Orange
Orbital action	-
Adjustable speed	Yes
Idle stroke rate (max)	- spm
Power source	Battery
AC input voltage	18 V

Weight and Dimensions

Weight	- g
