7
Cordless Jigsaw
EN
1. LOCK-OFF BUTTON
2. ON/OFF SWITCH
3. BATTERY PACK RELEASE BUTTON *
4. BATTERY PACK *
5. PENDULUM ACTION CONTROL LEVER
6. BASE PLATE
7. ROLLER GUIDE
8. SAW BLADE
9. CONTACT PROTECTOR
10. TOOL-FREE BLADE HOLDER
11. VACUUM ADAPTER (SEE FIG. B3)
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
WX543L WX543L.9
Voltage 20V
Max*
No load speed 0-2600/min
Stroke length 15/16”
Cutting
capacity
Wood 3-15/16”
Aluminum 25/32”
Steel 25/64”
Bevel capacity 0±45°
Weight 5.3 lbs 4.4 lbs
* Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.
ACCESSORIES
WX543L
WX543L.9
Charger (WA3742)
1 /
Battery pack
(WA3520)
1 /
Wood cutting blade
1 1
Vacuum adapter
1 1
Hex key
1 1
We recommend that you purchase your accessories
listed in the above list from the same store that sold
you the tool. Refer to the accessory packaging for
further details. Store personnel can assist you and
offer advice.
