13
EN
COMPONENT LIST
1. ON / OFF SWITCH
2. HAND GRIP AREA
3. BATTERY PACK *
4. BATTERY PACK RELEASE BUTTON*
5. SPINDLE LOCK BUTTON
6. SPINDLE
7. WHEEL GUARD FOR GRINDING
8. WHEEL GUARD FOR CUTTING
9. METAL CUTTING DISC
10. CLAMPING BOLT WITH WASHER
11. HEX KEY
12. ABRASIVE CUTTING DISC
13. GRINDING DISC
*Not all the accessories illustrated or described are included in standard
delivery.
TECHNICAL DATA
Type WX801 (80 - designation of machinery, representative of Angle
grinder)
WX801
WX801.9
Rated voltage
20V
Max**
Rated speed
19500rpm
Spindle thread M6
Thickness of metal cutting disc 1.2~1.4mm
Thickness of abrasive cutting disc 1.6mm
Thickness of grinding disc 4mm
Disc size 76mm
Disc bore 9.5mm
Machine weight 1.1kg 0.7kg
