Securing the L-bracket
Secure each of the L-brackets to the top rear
of the unit using 2x15mm screws at each side.
Page 4
Notching out the side panels (when
required)
In order to allow for any horizontal pipework
running behind the unit, some unitswill
require the back of the unit sides to be
notched out.
Create a notch for the horizontal pipes at the
back of the end panels using a jigsaw.
Lifting the unit into place
When lifting the unit into place do not tilt as
this can damage the legs.
Place the unit against the wall and align it
with the wall markings that will have been
drawn during the room preparation stage.
Use a spirit level to ensure the unit is
level from front to back, left to right, and
diagonally. Adjust the legs if required.
The leg height can be adjusted by turning the
foot of the leg clockwise or anti-clockwise.
