TOWER UNIT
Inframed kitchen Tower Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 14
Step 4.
Attach packer pieces to the end of the unit using 4 x 20mm countersunk
screws. Packer pieces are the same height as the unit.
Make sure that the screw head is fully ush with the surface of the packer
piece. Be careful not to insert the screw too far as it will protrude into the unit.
Step 3.
Cut decor panel to size.
Height of the decor end panel will be the height of the unit including legs + 30 and will be the same height
as the end rails.
