TOWER UNIT
Inframed kitchen Tower Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 20
Step 12.
Using 2 x 40mm countersunk screws per unit, attach the top and bottom front rails to the
top and bottom xed shelves on the unit.
Make sure that the front of the rails sit 0.5mm back from the front of the side rails and is
evenly spaced from the front of the unit along the entire length.
Cover screw heads with cover caps.
