WALL UNIT
Inframed kitchen Wall Unit Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 22
Step 4.
Attach packer pieces to the end of the unit using 2 x 20mm countersunk screws.
Packer pieces are the same height as the unit.
Make sure that the screw head is fully ush with the surface of the packer piece.
Be careful not to insert the screw too far as it will protrude into the unit.
Step 3.
Cut decor panel to size. (Cut top edge of the decor).
Height of the decor end panel will be the height of the unit + 60mm and will be the same height as the end rails.
To Next Page
