Wren INFRAMED KITCHEN - Page 35

BASE UNIT
Inframed kitchen End-Run Dishwasher Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 35
Step 7.
Attach 2 x Large L brackets on the inside face of the decor end panel where the panel meets the oor
using 2 x 15mm screws each.
Step 8.
Attach 2 x Large L brackets on the inside face of the decor end panel where the panel meets the wall
using 2 x 15mm screws each.
FRONT
FRONT
INSIDE FACE
INSIDE FACE
