Wren INFRAMED KITCHEN - Page 34

BASE UNIT
Inframed kitchen End-Run Dishwasher Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 34
Step 5.
Using a pocket hole drill, drill the inside face of the end panel that will be at the front of the unit in 4 equally
spaced locations.
Step 6.
Using 4 x 30mm pan head screws, attach the front vertical rail to the decor end panel.
Make sure that the Decor End panel is ush with the end of the vertical rail.
INSIDE FACE
INSIDE FACE
FRONT
FRONT
