Wren INFRAMED KITCHEN - Page 43

BASE UNIT
Inframed kitchen Mid-Run Dishwasher Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 43
Step 5.
Repeat step 11 for the rear unwrapped rails.
Step 6.
Using 2 x 15mm screws per L bracket attach 2 x Large L Brackets at both ends of the unwrapped rail
construction.
UNDERSIDE OF REAR RAIL ASSEMBLY
30mm
