Wren INFRAMED KITCHEN - Page 42

BASE UNIT
Inframed kitchen Mid-Run Dishwasher Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 42
Step 3.
Using a pocket hole drill, drill 2 holes at both ends of one of the top wrapped rails.
Step 4.
Pilot drill then, using 4 x 45mm screws, screw the front wrapped rail to the drilled front wrapped rail, osetting
the fronts of the rails by 30mm. Make sure that the rails are aligned and ush at the ends.
30mm
