LOWER TRACTOR (48 - 52 - 61)
REF # PART # DESCRIPTION REF # PART # DESCRIPTION
**1 51410009 ENGINE, KAWASAKI 15 HP RECOIL 51 16410001 SPRING, SMALL COMPRESSION
**1 51410005 ENGINE, KAWASAKI 17 HP RECOIL 52 98410027 NEUTRAL ADJUSTMENT KNOB W/ BOLT
**1 51410006 ENGINE, KAWASAKI 17 HP RECOIL/ELEC 53 12990022 NUT, NYLOCK JAM 1/2-13
**1 51410014V ENGINE, KAWASAKI 19 HP ELECTRIC 54 72490001 WHEEL, PLASTIC, 5" X 2 3/4" W/ 5/8 BORE
**1 51410013V ENGINE, KOHLER COMMAND 23 HP ELECTRIC 55 13990016 MACHINE BUSHING 5/8 ID 1 OD 14 GA
**1 51410010V ENGINE, KAWASAKI 23 HP ELECTRIC 56 11990022 BOLT, SHOULDER ALLEN 5/8 X 2 3/4
**1 51410029V ENGINE, KAWASAKI 25 HP ELECTRIC 57 11990024 SCREW, TRUSS HD MACHINE 1/4-20 X 3/4
2 36410003 OIL DRAIN VALVE, BALL VALVE TYPE 58 93410004 PULLEY GUARD PLATE
3 81410017 TUBE, OIL DRAIN 59 93410001 FOOT PLATFORM
4 15990002 CLIP, HALF 5/8" 60 12990018 NUT, NYLOCK JAM 1/2-20
5 35410018 OIL DRAIN VALVE ADAPTER (KAW ONLY) 0-ring NOT incl. 61 13990002 WASHER, FLAT USS 7/16 Z
6 35410017 COUPLING, BRASS, 3/8 NPT (KOHLER ONLY) 62 96410002 FOOT PLATE JOINT, ZINC PLATED
7 35410016 NIPPLE, BRASS, 3/8 NPT CLOSE (KOHLER ONLY) 63 11990011 BOLT, HEX 1/2-20 X 2 Z5
8 11990009 BOLT, HEX 5/16-24 X 1 1/2 Z5 64 93410009 TRACTOR FRAME WELDMENT
9 13990009 WASHER, FLAT USS 1/4 Z 65 93410014
Wheel Motor BRACKET, NOT
Interchangable W/65
10 12990011 NUT, LOCK FLANGE 5/16-24 Z 65A 93410018
Wheel Motor BRACKET, NOT
Interchangable W/65
11 11990027 BOLT, HEX 5/16-18 X 1 Z5 66 12990009 NUT, LOCK FLANGE 7/16-14 Z
12 16460001 SPRING, EXTENSION 68 11990046 BOLT, FLANGE 3/8-16 X 1 Z8
13 12990007 NUT, LOCK FLANGE 5/16-18 Z 69 72410017 WHEEL HUB, HEAVY-DUTY CAST (INCLUDES 4 x #103)
14 11990012 BOLT, FLANGE 5/16-18 X 3/4 Z5 70 12990023 NUT, CASTLE 3/4-14
14A 11990043 BOLT, SHOULDER ALLEN 3/8 X 3/4 71 15990012 PIN, COTTER 1/8" X 2
15 11990030 BOLT, FLANGE 3/8-16 X 3/4 Z5 72 15990015 WOODRUFF KEY 3/16 X 3/4
16 93410007 BRAKE SHOE 73 32410001 HYDRO MOTOR (MF16) (INCL #70 & #72)
17 12990008 NUT, LOCK FLANGE 3/8-16 73A 32410002 HYDRO MOTOR (MF14) (INCL #70 & #72)
18 93410008 BRAKE/TRANS INTERLOCK COG (old-no spring used) 74 72410004 TURF TIRE ONLY 10" X 20" TURFMATE
18A 93410033 BRAKE/TRANS INTERLOCK COG (uses spring) 74A 72410011 TURF TIRE ONLY 10" X 20" TURFMASTER
19 Discontinued BRAKE, LATERAL LINK BAR (Type without cog spring) 75 72410005 RIM ONLY 10" X 20" (ALL)
SERIAL NUMBERS AFTER 12624 EQUIPPED WITH 19A 76 72410002 TIRE & RIM ASSEMBLY (TURFMATE)
REPLACE WITH 19A & 2 EACH 14A, 97, 18A, 21, 101 76A 72410012 TIRE & RIM ASSEMBLY (TURFMASTER)
19A 93410017 BRAKE, LATERAL LINK BAR (Spring cog type) 77 72410001 NUT, LUG 1/2-20
20 93410005 TRIGGER, OPC 78 71410004 SETSCREW 5/16-18 X 3/8
21 13990010 WASHER, FLAT USS 5/16 Z 79 15990004 MACHINE KEY 5 MM X 5 MM X 25 MM
22 16410002 SPRING, LARGE COMPRESSION 80 71410003 PULLEY 5.45 OD x A GRV x 15MM
23 13990001 BUSHING, NYLON FLANGE *81 71460001 BELT AX-50, FOR HYDRO PUMPS (USED W/ #84) see note*
24 52410001 SWITCH, OPC (GRAY), NORM. CLOSED *81A 71460033 BELT AX-51, FOR HYDRO PUMPS (USED W/ #84A) NEW
24A 52410002 SWITCH, OPC (BLACK), NORM. OPEN 82 15990003 MACHINE KEY 1/4 SQ. x 1
25 93410011 BRACKET, OPC (WORKS WITH #24) 83 71460006 PULLEY, IDLER 4 1/2 x 1 x 3/8 BORE
25A 93410015 BRACKET, OPC (WORKS WITH #24A) *84 71410002 PULLEY 4.5 OD x A GRV x 1" (see note below*)
26 13990005 WASHER, RUBBER 3/8 *84A 71410005 PULLEY 5 1/16" OD x A GRV x 1" NEW (see note below*)
27 13990004 WASHER, FENDER, 5/16 X 1 Z 85 71410001 CLUTCH/BRAKE (YELLOW WIRE SLEEVE)
28 85410009 THREADED ROD FOR OPC (BENT) 86 71410007 SPACER, FOR CLUTCH
29 15990007 HITCH PIN CLIP 87 11990010 BOLT, HEX 7/16-20 X 2 3/4 Z5
30 15990009 E-CLIP 1/2 88 11990006 BOLT, HEX 3/8-16 X 2 1/2 Z5
31 13990015 MACHINE BUSHING 1/2 ID 7/8 OD 18GA 89 93490001 IDLER ARM BASE
32 12990019 NUT, NYLOCK 1/4-20 90 14990001 BUSHING, BRONZE (SAME AS VELKE PIVOT BUSHING)
33 14990002 BUSHING, BRONZE(SAME AS VELKE HITCH BUSHING) 91 98490002 IDLER ARM W/ BUSHINGS (2 x #90)
34 98410006 RIGHT NEUTRAL ADJ LEV. W/ BUSHING (#33) 92 11990004 BOLT, HEX 3/8-16 X 1 1/2 Z5
35 98410007 LEFT NEUTRAL ADJ LEV. W/ BUSHING (#33) 93 13990017 MACHINE BUSHING 7/8 ID 1 3/8 OD 14 GA
36 98410008 PUMP CONTROL PIVOT BASE W/ BUSHING (#33) 94 12990020 NUT, NYLOCK 3/8-16
37 11990008 BOLT, EYE 1/4-20 Z 95 15990010 E-CLIP 7/8
38 11990002 BOLT, HEX 5/16-18 X 2 Z5 96 13990014 WASHER, LOCK 7/16 Z
39 11990019 BOLT, ALLEN 1/4-20 X 2 97 16410003 SPRING, TORSION FOR BRAKE SYSTEM
40 11990018 BOLT, ALLEN 10-32 X 2 98 36410004 FITTING, MALE BARB, STRT (KOHLER)
41 93410012 PUMP CONTROL HOOP, RIGHT 99 36410005 FITTING, MALE BARB, 90 DEG(BRIGGS & KAWASAKI)
42 93410010 PUMP CONTROL HOOP, LEFT 100 35410024 O-RING, FOR KAWASAKI OIL DRAIN ADAPTER
43 96410001 PUMP CONTROL CLAMP 101 12990021 NUT, NYLOCK 5/16-18
44 13990003 WASHER, FLAT SAE #10 102 16420002 SPRING, PUMP IDLER, NEW
45 12990016 NUT, NYLOCK 10-32 103 72410013 STUD, FOR TAPERED WHEEL HUB
46 11990025 SCREW, ROUND PHLP 1/4-20 X 2 Z 104 12990031 NUT, TOPLOCK 3/8-16
47 31490001 HYDRO PUMP * 81/84 NOTE: Serial # 12000+ have NEW / could be either if before #12000
48 11990017 BOLT, CARRIAGE, 7/16 X 1 Z5 **1 NOTE: All engines include entire exhaust (shipped loose)
49 11990013 BOLT, FLANGE 5/16-18 X 1 Z5
50 12990006 NUT, LOCK FLANGE 1/4-20 Z
(c) 1998-2001 Wright Manufacturing, Inc. All rights reserved. rev. 12/01
