Bulletin # 058
3 Pages
June 29, 2006
Re-routing Z hydraulic hose
Subject: Re-routing hydraulic hose part number 33410075
Units
Affected: All Mid-Mount Z mowers with a serial number
from 30200 through 34006
Situation: The hydraulic hose is routed below the hydraulic tank and can
come in contact with the deck belt. If this happens, the belt can
wear through the hose and cause the hose to leak
The Fix: Re-route the hose from the hanging position to up between the
hydraulic tank and mower frame as pictured below. The hose
fittings on the pump will need to be re-oriented to accommodate
this change as pictured below.
This work should be performed as quickly as possible on
each affected mower. Do not wait until the hose fails.
Claim
Procedure: 0.4 hours allowed if work performed within the normal warranty
period of the mower.
