Declaration of Conformity
Battery charger AL 60 U
Part number 702 343
Rated battery voltage (NTC) 7.2 V - 14.4 V
Mains voltage 230 V
Charging current
Rapid charging 1.9 A max.
Trickle charging 80 mA
Charging time 1.4 Ah approx. 50 min.
1.7 Ah approx. 60 min.
2.0 Ah approx. 71 min.
Degree of protection / II
❏ The mains voltage must comply with the specifica-
tions on the rating plate. 230 V battery chargers can
also be operated at 220 V.
❏ The battery charger is only suitable for charging
NTC batteries from the Würth range of tools with volta-
ges between 7.2 and 14.4 V.
❏ Use only genuine accessories.
Always inspect the plug and cable be-
fore use. If damaged, they must be re-
placed by a qualified professional.
❏ Charge only WÜRTH batteries and use only
genuine accessories.
❏ Keep the battery charger slot free of foreign ob-
jects and protect against contamination.
❏ Protect battery charger against humidity and
operate only in dry areas.
❏ Do not open the battery; protect against im-
pact, heat and fire. Danger of explosion!
❏ When the battery is outside the battery charg-
er, cover battery terminals to avoid short circuits
from metal objects. Danger of fire and explosion!
Recycling raw materials instead of waste disposal
Machine, accessories and packaging should be sorted
for environment-friendly recycling.
These instructions are printed on recycling paper ma-
nufactured without chlorine.
The plastic components are labelled for categorized re-
cycling.
WÜRTH offers an environment friendly battery dispo-
sal service: Defective batteries are sent off to undergo
a complete recycling process.
For Your Safety
GB
Tool Specifications
Before Use
Environmental Protection
Warranty and Service
Subject to change
Initial Operation
The charging process begins as soon as the mains
plug is inserted into the power supply socket and the
battery is placed into battery charger slot ➋. The char-
ging process is indicated by green light ➊.
The ”intelligent” battery charger recognises the char-
ged condition of the battery and switches a fully char-
ged battery immediately to trickle charging. By means
of this charging process, the battery is protected and
always fully charged.
Rapid charging is only possible when the temper-
ature of the battery is between 0 °C and 50 °C.
A new battery-operated tool or one which has not
been used for an extended period achieves full perfor-
mance only after five charging and discharging cycles.
A substantial drop in operating period per charge in-
dicates that the battery must be replaced.
Flashing green light
Rapid charging operates until the battery is fully
recharged. The battery charger then automatical-
ly switches to trickle charging.
Continuous green light
Battery not
inserted, mains voltage is on;
Continuous green light
Battery inserted
, the battery charger is only deli-
vering a trickle charge because the battery is al-
ready fully charged, or ...
Battery inserted
, the battery charger is only delive-
ring a trickle charge because the battery is too hot
(or too cold). The battery charger automatically
switches to rapid charging when a suitable tempe-
rature is reached.
Indicators and Meaning
We declare under our sole responsibility that this pro-
duct is in conformity with the following standards or
standardization documents. EN 50 144, EN 55 014
(Battery powered tools) and EN 60 335, EN 55 014
or EN 55 011, EN 60 555 (Battery charger) accor-
ding to the provisions of the regulations 73/23/EEC,
89/336/EEC, 89/392/EEC.
The unit is maintenance free.
WÜRTH tools carry a guarantee of 12 months from
date of delivery.
✄
01
Adolf Würth GmbH & Co. KG
Rolf Bauer ppa. Otto Steck
