26 English
Technical data
Subject to technical modifications.
ISS 40-M AUTOMATIC
Electrical connection
Mains voltage V 220-240
Phase ~ 1
Power frequency Hz 50-60
Degree of protection IPX4
Protection class I
Maximum power W 1380
Nominal power W 1200
Power rating of the device socket (max.) W EU: 100-2200
Power rating of the device socket (max.) W CH: 100-1100
Device performance data
Tank content l 39
Fluid filling quantity l 24
Air quantity (max.) m
3
/h 143
Vacuum (max.) kPa (mbar) 23,7 (237)
Dimensions and weights
Filter area of the flat fold filter m
2
0,6
Diameter of the suction hose mm 35
Length of the suction hose m 3,0
Length x width x height mm 560 x 370 x 655
Typical operating weight kg 15,1
Determined values in acc. with EN 60335-2-69
Sound level L
pA
dB(A) 68
K uncertainty
pA
dB(A) 2
Hand-arm vibration value m/s
2
<2,5
K uncertainty m/s
2
0,2
Mains cable
Power cord type H07RN-F 3x1,5 mm²
Item number EU: 0707 133 100
Item number CH: 0707 133 101
Cable length m 7,5
