Würth Master H 26-MLS User Manual

12
Product specifications
Rotary hammer H 26-MLE H 26-MLS
Article number 0702 226 X 0702 227 X
Rated power 800 W 800 W
Speed control • •
Rotation off • •
Clockwise/counter-
clockwise rotation
• •
Replaceable chuck — •
Rated speed
- Clockwise rotation 0–900 rpm 0–900 rpm
- Counter-clockwise
rotation
0–900 rpm 0–900 rpm
No-load speed 1,300 rpm 1,300 rpm
Impact rate 0–4 000
rpm
0–4 000
rpm
Impact energy per
stroke
3.0 J 3.0 J
Tool holder,SDS-plus • •
Spindle collar
diameter Ø
50 mm 50 mm
Chisel positions 36 36
Drilling performance
(max.):
- Masonry (core bit) 68 mm 68 mm
- Stone, concrete 26 mm 26 mm
- Wood 30 mm 30 mm
- Steel 13 mm 13 mm
Weight (without
accessories)
Approx.
2.7 kg
Approx.
2.9 kg
Protection class / II / II
Product features
1 Keyless replaceable chuck (H 26-MLS)
2 SDS-plus replaceable chuck (H 26-MLS)
3 Tool holder (SDS-plus)
4 Dust protection cap
5 Locking sleeve
6 Replaceable chuck locking ring (H 26-MLS)
7 Rotational direction switch
8 Lock-on button for On/Off switch
9 On/Off switch
10 Release button
11 Mode selector switch
12 Button on the auxiliary handle
13 Depth stop
14 Auxiliary handle
15 Replaceable chuck holder (H 26-MLS)
16 Front sleeve on the keyless replaceable chuck
(H 26-MLS)
17 Retaining ring for the keyless replaceable chuck
(H 26-MLS)
18 Extraction clamping screw*
19 Extraction depth stop*
20 Extraction telescopic tube*
21 Extraction wing screw*
22 Extraction guide tube*
* Not all of the accessories illustrated and de-
scribed are included as standard.
Correct use
The product is intended to be used for hammer drilling
in concrete, brick and stone as well as for chiselling
work. It is also suitable for drilling without hammer ac-
tion in wood, metal, ceramic and plastic.
The user is liable for damage caused by incorrect use.
If you have any queries on the product and its use, in
Germany our product and application consultancy
service will be pleased to be of assistance, tel.: 01805-
60 65 69 (12 cent/min).
Inserting / changing tool
qWhen changing the tool, make sure the dust pro-
tection cap is not damaged!
SDS-plus tools
Due to the nature of the design of SDS-plus tools, the
tool is free to move. This movement will result in radial
run-out under no-load; this run-out is automatically cor-
rected during drilling. This feature will not impair the
accuracy of the hole drilled.
Inserting SDS-plus tools (Figure I)
H 26-MLS: Fit SDS-plus replaceable chuck (see Chang-
ing SDS-plus replaceable chuck).
H 26-MLE / H 26-MLS: Clean and lightly grease the
end of the tool to be inserted prior to insertion. Push
the tool into the tool holder 3 with a twisting action
until the tool locks.
The tool locks automatically. Check locking by pulling
the tool!
Removing SDS-plus tools (Figure II)
Push back (a) the locking sleeve 5 and hold in this
position. Remove tool from the tool holder (b).
