X – 60 Instructions Version 1.0 Page 30
ELECTRONICS
D4) As a tuning option, we have included two sets of mounting holes for the
servo, forward and back. Check the Tuning Section and Set-up sheet to
see which you will use. These photos show the servo in the forward
position. The servo installs with the two saved flat-head screws from the
bottom just as in the T4.
D5) Re-attach the servo link just as it
was in your T4.
D6) Install the motor using the two
motor screws from your T4.
