24
X-1005
EYEWEAR ADAPTIVE
1 CREATING SPACE FOR THE EYEWEAR
1.1 Remove the left cheek pad from the helmet (see instructions above).
1.2 Remove the inner expanding foam cheek padding (see instructions above).
1.3 Remove the upper part of the pre-punched inner padding (Fig.23), then correctly
reposition the remaining part of the padding in the cheek pad.
It is recommended that you keep the removed padding for reuse in the future
1.4 Ret the inner expanding foam cheek padding of the cheek pad (see instructions
above).
1.5 Ret the full cheek pad on the helmet (see instructions above).
1.6 Repeat these steps with the padding of the right cheek pad.
2 CLOSING SPACE FOR THE EYEWEAR
2.1 Remove the left cheek pad from the helmet (see instructions above).
2.2 Remove the inner expanding foam cheek padding (see instructions above).
2.3 Properly insert part of the previously removed padding into the fabric lining cover
of the cheek pad (Fig.23).
2.4 Ret the full cheek pad on the helmet (see instructions above).
2.5 Repeat these steps with the padding of the right cheek pad.
WIND PROTECTOR
(Available as standard or accessory/spare part)
This accessory allows improved helmet performance under certain conditions of use.
The Wind Protector reduces unpleasant inltrations of air under the chin.
See Fig.24 for assembly and disassembly instructions.
VENTILATION SYSTEM
The ventilation system of the helmet consists of:
Lower ventilation
It allows ventilation around the mouth and channels the air directly on the visor to
reduce fogging.
See Fig.25 for opening and closing instructions.
Top ventilation
It allows diffuse ventilation to the top of the head, even at low speed.
See Fig.26 for opening and closing instructions.
Rear ventilation
It is integrated in a rear spoiler and allows warm and stale air to ow out ensuring an
optimum comfort inside the helmet (Fig.27).
INSTRUCTIONS FOR USE
