XAC RP-10 - Powering and Using Card Readers; Power On;Off the Device; Using the Magnetic Card Reader; Using the IC Card Reader

■ RP-10 power spec:
Input:5VDC,0.5A

 OperatingTemperature:0
o
Cto40
o
C

3. POWER ON/OFF THE DEVICE

Topoweronthedevice,pleaseplug theUSBcableintotheUSBportofyourhostterminalor
POS.
Note:WhenthereisnoactiononRP‐10after60seconds,thedevicewillenterpowersaving
mode.Pleaseshortpressanybuttononkeypadtowakeupthedevice.

4. USING THE MAGNETIC CARD READER

Swipe the card through the slot with magnetic stripe side facing the same direction as the
display.(Figure3)
Figure3
5. USING THE IC CARD READER

Insert an IC card into the  slot (Figure 4) with the chip side facing the same direction as the
touchpanel(Figure5).
Figure4Figure5
