LED Indicators – Resource and Port Description/Status
LED
Status
Status
Description
POWER
Power status
On - Green
Power ON
Off
Power OFF
System
System status
Blinking – Green
The system is running properly
Steady/Off
The system is not running properly
WAN
WAN status
Steady – Green
Network Link is active
Blinking – Green
Data Traffic detected (normal)
Off
Off-line
LAN
LAN status
Steady – Green
Linked normally
Blinking – Green
Data Traffic detected (normal)
Off
Off-line
Analog Port
Status
Analog
Extension (FXS)
Green Steady
Green Blinking
• The port is idle
• There is an ongoing call on the port
Analog Line
(FXO)
Red Steady
Red Slow Flash
Red Fast Flash
• PSTN Line is idle
• No PSTN line is connected to the port
• The PSTN line is busy
Cellular
GSM/CDMA/3G
Red Steady
Red Slow Flash
Red Fast Flash
• Line is idle
• No SIM card detected
• Line is in use
