8
VIPER CUT30 PLASMA
30 Amp Inverter Plasma Cutter
Cuts: Steels, Stainless, Cast Iron, Brass, Copper. Aluminium
VIPER CUT30
Optional machine accessories available - refer www.xcelarc.nz
XA-CUT30V
Standard Package
Technical Data
Power Supply / Phases (V-Ph) 230V - 1 +/- 10%
Rated Input Power 7.50 kVA
I
i
e as per AS/NZ60974-1 10.0 Amps
I Max 25.0 Amps
Plasma Cut Current Range 20-30 Amps
Duty Cycle @ 40°C
as per AS/NZ60974-1 15% @ 30Amps
Duty Cycle @ 25°C
(approximate) 35% @ 30Amps
No Load Voltage 310V
Plasma Arc Start Pilot Arc
Air Flow Draw O 6.7 cfm
Air Pressure 70-87 psi
Steel Cut Thickness 12mm
Steel Sever Thickness 14mm
Aluminium Cut Thickness 6mm
Aluminium Sever Thickness 8mm
Stainless Cut Thickness 6mm
Stainless Sever Thickness 8mm
Insulation Class F
Protection Class IP21S
Dimensions
(LxWxH) 460x160x320mm
Weight Power Source 11.6kg
Certication Approval AS/NZ60974-1
Features
■ Modern IGBT inverter technology
■ Non-commercial application
■ Excellent performance from single-phase
■ Pilot Arc Ignition (non-contact)
■ Drag-Tip cutting with Stand-O capability
■ Maximum sever cutting thickness (steel) 12mm
■ High quality Surecut CBR150 Plasma Torch 4mtr
■ Direct-Connect Plasma Torch, low-cost consumables
■ In-built adjustable air regulator
■ Suitable to cut all electrically conductive materials
■ Lightweight & compact design
■ Strong metal housing
■ Generator compatible (recommend 7.5KVA minimum)
■ Tolerant to variable power supply
Entry Level Inverter Plasma Cutter
30 Amp 230V Single Phase
12mm Cut on Mild Steel
Product Code: XA-CUT30V-K
Standard Package includes: VIPER CUT30 Machine, Direct connect SC40 Plasma Torch 4m, Direct Connect 3m Earth Lead
Overview
The VIPER CUT30 from Xcel-Arc is a new generation, low cost single phase Plasma Cutting machine produced using modern IGBT
inverter technology. Designed to meet the needs of the price conscious non-commercial user without compromising on quality, this ma-
chine is as reliable and robust as you would expect a machine bearing the Xcel-Arc name to be. The VIPER CUT30 produces a high tem-
perature plasma stream enabling ecient cutting of all electrically conductive materials including steel, cast Iron, stainless steel, copper,
aluminium brass etc. The high quality Suregrip SC40 Plasma Torch provides non contact Pilot Arc Ignition allowing for postive clean starts
everytime. The Direct-Connect SC40 Plasma Torch with 4mtr cable uses low-cost wear consumables with the additional benet of longer
life cycle of both Electrodes and Cutting Tips. The VIPER CUT30 is an exceptional machine for the price and is suitable for a wide range
of applications including light engineering, sheet metal fabrication, site work, automotive panel repair, ducting work and general repair and
maintenance work. The VIPER CUT30 oers great portability with the power to get the job done at a great price.
Built to our specication and manufactured in compliance to AS/NZ60974-1
