XCEL Q-SERIES User Manual

13
8. MULTI-STAGE CHARGE (TYPICAL) WITH LCD DISPLAY
 Use of an LCD Display, does not affect nor alter the charge process in any way.
It only converts messages from what is otherwise a blinking LED into readable
characters. Therefore, refer to the previous section for a description of a typical
charge stage and reference the displayed LCD messages, below.
 Menu Select Button:
o Depressing and holding depressed this button for 10 seconds at power up,
forces charger to insert the Equalization Stage into the charge algorithm
regiment IF and only IF, that charge MODE selected, would allow it. After
power up, and if switch is again held depressed for 10 seconds, the
Equalization Charge Stage is toggled to OFF (de-asserted from the charge
algorithm Regiment).
o If depressed for at least 1 second, but released less than 10 seconds, the
menu display toggles up to the next incremental menu and stays active for
approximately 30seconds before reverting back to the default menu in effect
previously. You will know when the 1second period has been reached
because the LCD Backlight will ‘Blink’.
 Five Menus are made available and are selectable via the Menu Select Button:
 Annunciation (Start Up) Menu
 Charge Status And Output Display
 Charge Status And Input Display
 Error Code Display
 Charge Status and Temperature Display
 ANNUNCIATION (START UP) MENU
o Display shows (assume 24V Battery Charger):
 MD: MODE is annunciated as ‘2’, MODE-2
 TYPE: Type is annunciating the battery type as:
 225 Ampere Hour Size
 Battery Pack Class is ‘02’ – Flooded Lead Acid
 Refer to Battery Type Class Table for full list
 STAT: Status Identifier. Refer to Status Identifier Table
 This menu displays as the default menu during the initial 4 second
power-on start up
 Battery Type Class Table:
01: AGM Lead Acid Battery 02: Flooded Lead Acid Battery
03: GEL Lead Acid Battery 04: Pure Lead – Lead Acid Battery
05: Spiral Lead Acid Battery 06: Uncategorized Lead Acid
07: Lithium Based Battery 08: Molten Salt Based Battery
09: Nickel Based Battery 10: Organic Based Battery
11: Potassium Based Battery 12: Silicon Based Battery
13: Silver Based Battery 14: Sodium Based Battery
o Call factory for additionally available Algorithms developed for rechargeable
chemistries that can be downloaded into a spare MODE. Also, refer to the
‘Accusense Charge Suite Application’ section for further details.
MD ---TYPE--- STAT
02 0225Ah02 --HF--
