XCHARGE C6EU DC charging station
Preventive maintenance instructions
XCHARGE Europe GmbH, Borsteler Bogen 27 A, 22453 Hamburg, Germany http://www.xcharge.com/en/
Check the
charging point
connections
CP1 CHAdeMo
CP2 CCS
1 year
4 min.
Check the charging points for wear, damage to plugs, cables
and holders. Check that the cable glands are tightened and
that there is no risk of electric shock. Check that the charging
cables are correctly and firmly connected to the connection
points inside the charger.
Control of the SPD over-
voltage protection
1 year
1 min.
Check the display window on the surge protection module. If
red, the surge protection module must be replaced.
Control of RFID functiona-
lity
1 year
1 min.
Check that the RFID reader can recognise and read the RFID
cards.
Control of antennas
1 year
1 min.
Check that the antenna is not damaged and that there are no
traces of water leaking through the antenna to the inside of
the charger.
Control of the controller
DCB and A8
1 year
5 min.
Check that there is no damage to the boards or corrosion. All
cables must be firmly connected.
Checking the fans
1 year
6 min.
Check that the fans are not damaged and that no deposits
have formed on the fan or rotor blades.
Test of the RCDs
1 year
2 min.
Test the RCDs with the test button on the main switch.
Note: the total 1 year maintenance inspection period last on average 58 minutes, however the actual duration may vary, but
should not exceed 90 minutes.
Check the protective con-
ductor connections
3 years
10 min.
Check that all accessible conductive components are con-
nected to the earth rail. The resistance must be <0.1 Ohm.
Inspection of the insulation
resistance (removal of the
surge protection and the
rectifier modules, discon-
nection of the control unit)
3 years
20 min.
The insulation resistance between the power cables and the
protective conductor >1MΩ at 500VDC
Check that the insulation resistance between the wires is >
1MΩ at 500VDC.
