XS9900D Xcruiser Satellite-Meter ENG- 11
No Description
1 LNB-IN Digital satellite signal input
3 LC-Display Display of the TV picture, the menu and the measured values
18 POWER-LED
Display of the energy state:
Operation:
red: the measuring devise is switched on.
Off: the measuring devise is switched off.
In charge:
Green: The battery is charged
Red: The battery is full charged
19 LOCK-LED LED lights when a signal is received.
4 FUNCTION keys F1: toggle the Display
F2: Mute
F3: Additional information about the current program
F4: switch between radio/TV mode
5 22K/13V/18V-LEDs Lights if 22K/13V/18V signals are received
6
Navigation-cross
OK - button
Navigation through menus, switching programs
▲, ▼volume control ◄, ►
OK button: confirmation of a selection
11 Numeric keys Direct enter of numbers
7 FIND-button FIND menu: for a quick and easy alignment of a satellite antenna
12 Menu-button Display the main menu
17 EXIT-button Leave the current menu, cancel operation
8 ANGLE-button Display the calculation menu
10 SYSTEM-button
Configuration of all system parameter.
Display current software version.
To Next Page
