Xerox 100 - System Productivity: with Basic Finishing Module

Xerox Nuvera
®
100/120/144 EA Digital Production System - Customer Expectations Document
- 50 -
Table 1: BFM System Main and Top Tray Paper Size Range
BFM / BFM Plus System Standard Paper Sizes
Paper Size Orientation
Output Tray
Name
Nuvera
®
144
Simplex
PPM
Inch (WxL) mm (WxL) LEF SEF Top
Main
226x310 72* (8.89x12.2) 226x310 x
9x14 72* 9x14 (229x356) x
SB4 72* (9.9x14.1) 252x358 x
B4 (JIS) 72 (10.12x14.33
)
257x364 x
8K (Taiwan) 72* (10.51x15.2) 267x388 x
A3 72* (11.69x16.54
)
297x420 x
Ledger 72* 11x17 (279x432) x
12x18 48 12x18 (305x457) x
12x18.5 48 12x18.5 (305x470) x
310x432 72* (12.2x17) 310x432 x
Transparency 144 8.5x11 ( A4) 216x279 x
SRA3 4up A5 48 12.6x17.7 320x450 x
4up 6”x9” 48 12.5x18.5 317.5x470 x
2up 6”x9” 96 12.5x9.5 (317.5x241.3) x
SRA4 2up A5 120 (12.6x8.9) 320x225 x
Media less than 6.85 inches (174 mm) in the process direction are not supported in the BFM stacker.
System Productivity: Xerox Nuvera
®
120 / 144 EA DPS
with Basic Finishing Module
Productivity will be slightly less for jobs with only 1 or 2 sheets per set.
Output to Top Tray
Simplex to simplex; duplex to duplex
Single-sided sheets printed per minute Double-sided sheets printed per minute
Paper Size
30 page job 10 page job 3 page job 30 page job 10 page job 3 page job
8.5” x 11” 120 / 144 120 / 144 120 / 144 60 / 72 60 / 72 60 / 72
8.5” X 14” ** 72 72 72 36 36 36
11” X 17” 72 72 72 36 36 36
** 8.5” X 14” paper feeds “Short-edge” as defined in the system.
Output to Main Stacker – Stapled (Single and Dual staples) and Unstapled
Simplex to simplex; duplex to duplex
Single-sided sheets printed per minute Double-sided sheets printed per minute
Paper Size
30 page job 10 page job 3 page job 30 page job 10 page job 3 page job
8.5” x 11” 120 / 144 120 / 144 120 / 107 60 / 72 60 / 72 60 / 65
8.5” X 14” ** 67 60 43 34 30 22
11” X 17” 67 60 43 34 30 22
** 8.5” X 14” paper feeds “Short-edge” as defined in the system.
