PAPER AND OTHER SUPPLIES
XEROX DOCUPRINT 96/4635/180 NPS SYSTEM OVERVIEW GUIDE A-5
The following figure illustrates the maximum and minimum paper
sizes supported in 8-pitch mode.
Figure A-1. 8-pitch mode paper sizes (4635 and 180 only)
1 Maximum paper size for 8 pitch mode
2 Minimum paper size for 8 pitch mode
3 Travel direction of sheets out of paper tray
Using large paper sizes in 3-pitch mode:
Large paper sizes—widths of 15.31 to 17 inches / 389 to 432 mm—
are supported only in 3-pitch mode and must feed short edge first.
These paper sizes slow down the throughput speed (as shown in
tables above).
Note: The 96/4635/180 printer can support 14 by 17-inch / 356 by
432 mm, 20 pound or 80 gsm paper stock in 3-pitch mode. However,
printing performance is not guaranteed for all types of paper of this
size. Heavy (110-pound / 200 gsm) and light (16-pound / 60 gsm)
large papers can cause jams throughout the system and are not
recommended.
