Integrated Fiery Color Server SERVICING
CONFIGURATION TRAINING GUIDE 7/09 3-5
Service
Follow standard ESD (electrostatic discharge) precautions while
working on the internal components of the Integrated Fiery Color
Server.
LED diagnostic codes
During startup, the Fiery advances through a standard
diagnostic sequence. Each diagnostic code flashes rapidly on
the LED display during this sequence until the Fiery reaches
Idle. At Idle, the LED display shows the 00 code, indicating that
the Fiery is in normal operation mode.
To Access and Open the Fiery
1. Make sure that the Fiery Controller is not receiving,
processing, or printing any jobs.
2. Power off the Fiery Controller by moving the Fiery
Controller power switch to the OFF (O) position.
3. Make sure the copier is not in use, and power off the copier
using the main power button on the left.
Wait for the Fiery Controller and copier to power off
completely. The Fiery Controller LED display turns off when
the Fiery Controller finishes powering off.
4. Remove all external cables from the Fiery Controller
connectors.
5. Place the Fiery Controller on an antistatic surface.
Position the Fiery Controller so that the four mounting tabs
rest flat against the antistatic surface.
Checking Integrated Fiery Color Server Internal
Connections
For the procedures to Check the Integrated Fiery Color Server
Internal Connection, consult the Integrated Fiery Color Server for
Xerox Color 550 Production Printer Installation and Service Guide
Series for Xerox Color 550 Production Printer, Service Procedures.
This includes the following sections:
o To Check Cable Connections
