SquareFold Trimmer User Guide
9
Overview
Tip: The following table shows various scenarios using
different paper weights, media types, and trim setting
selections. Use this table as a guideline when selecting a
trim setting for your specific job. The settings shown in the
following table are provided as examples
and are not
meant to represent every possible job scenario; again, use
this table as a guideline only.
Scenario
number
1
Paper Size Finished booklet
size
Paper weight
(lbs./g/m²)
Approximate Trim
setting (mm)
Number of
pages in finished
booklet
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
20 lbs./75g/m² 130 20
2 8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
24 lbs./90 g/m² 125 14
3
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
32 lbs./120 g/m² 135 10
4
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
20 lbs./75g/m² 125 10
5
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
80 lbs./120 g/m² 135 12
6
8.5 x 14 in./B4 (250 x
353 mm)
8.5 x 7 in./250 x 176.5
mm
20 lbs./75g/m² 172 6
8
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
24 lbs./90 g/m² 200 14
10
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
20 lbs./80 g/m² 210 22
7
8.5 x 14 in./B4 (250 x
353 mm)
8.5 x 7 in./250 x 176.5
mm
24 lbs./90 g/m² 170 6
9
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
80 lbs./216 g/m² 205 5
11
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
24 lbs./90 g/m² 210 8
12
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
80 lbs./120 g/m² 205 10
13
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm 80 lbs./120 g/m² 220 6
14
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm 80 lbs./216 g/m² 215 5
15
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm 80 lbs./210 g/m² 210 4
16
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm 28 lbs./ 105 g/m² 220 16
17
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm 80 lbs./120 g/m² 210 14
