Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-35
Parts List 4.1 Duplex Assembly
Item Name Part Number
0 Duplex Assembly 022N02676
1 Duplex Base Frame
2 Dup Feed M Bush
3 Dummy Dup 18 M Pulley
4 18 Dup Pulley
5 F/Down Exit Gear
6 Gear Timing Belt
7 Timing Belt
8 Feed DUP2 Roller
9 Feed Dup Roller
10 Align Duplex Lever
11 Paper Duplex Guide
12 Duplex GND Terminal
13 Duplex Align Bracket
14 Tapping Screw
15 Dup Roll Idle Shaft
16 Washer Silp PCT
17 Idle Dup M Roller
18 TS Spring
19 Duplex Upper Guide
20 Duplex Gasket
