Xerox WorkCentre 3315 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-37
Parts List 5.1 Tray 1
Item Name Part Number
0 Cassette (Tray 1) 050N00650
2 Cassette Frame
3 Locker Plate Spring ETC
4 Pinion Gear
5 Right Cassette Guide
6 Right Side Guide
7 Right Side Lever
8 Right Side Stopper
9 CS Spring
10 Rear Guide Knob
11 Pad Spring ETC
12 F/UP Idle Shaft IEX
13 Left Guide Cassette
14 Left Side Guide
15 F/UP Idle Shaft IEX
16 Paper Indicator
17 Cassette Locker
18 CS Spring
19 Cassette Ground
20 Knock Up Plate P
21 Cassette Pad RPR (Base Plate Pad) 050N00646
22 CS Spring
23 Retard Roller Cassette 050N00649
24 Torque Limiter Coupler
25 TL Rubber
26 Retard Shaft Holder
27 CS Spring
28 Cassette Cover
29 Retard Sheet
30 Cassette Sheet
31 Rear Guide Cassette
32 Rear Paper Guide
33 Right Guide Locker
34 Left Guide Locker
35 Slide Guide Locker
36 Rear Guide Lever
37 Upper Rear Adjust
38 Lower Rear Adjust
39 Rear Adjust Locker
40 Lock Guide Support
41 Guide Rear Knob
42 CS Spring
43 Pad Spring ETC
44 Cassette Handle
45 Bottom CST Absorber
46 Printing Caution Label
www MK-Electronic de

Xerox WorkCentre 3315 Specifications

General

Print Technology	Laser
Duplex Printing	Manual
Functions	Print, Copy, Scan, Fax
First Page Out Time	As fast as 6.5 seconds
Copy Resolution	Up to 600 x 600 dpi
First Copy Out Time	As fast as 10 seconds
Fax Speed	33.6 Kbps
Print Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Paper Sizes	Letter, Legal, A4, A5, Executive
Scan Resolution	Up to 4800 x 4800 dpi
Weight	25.1 lbs
Operating System Compatibility	Windows, Mac, Linux
