Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-41
Parts List 7.1 ADF (1/2)
Item Name Part Number
0 ADF (Cushion not included. See PL 9.1, item 1.5) 022N02680
1 ADF Top Cover
1.1 Cover ADF CSP
1.2 Pick Up Module
1.2.1 Pick Up Housing CSP (with 1,2,7) 130N01672
1.2.2 Chess Ring CSP
1.2.4 Gear Drive Pick CSP
1.2.5 Idle Gear Pick CSP
1.2.6 Gear Separate Roller CSP 130N01673
1.3 Idle Roller Module
1.3.1 Roller Idle CSP
1.3.4 Frame Idle Unit CSP
1.4 Stopper Paper CSP
2 ADF Base Frame See
page 5-43
2.1 Cover Platen CSP S
ee page 5-43
2.2 Stopper Output CSP See page 5-43
2.3 Slide Stopper CSP See page 5-43
3 Paper Path Assembly S
ee page 5-43
4 ADF Motor 127N07781
5 Input Tray
5.2 Pinion Gear CSP
5.4 Stacker CSP
5.5 Rear Edge Guide CSP
5.6 Front Edge Guide CSP
6 Rear ADF Cover CSP
7 Front ADF Cover CSP
www MK-Electronic de

Xerox WorkCentre 3315 Specifications

General

Print Technology	Laser
Duplex Printing	Manual
Functions	Print, Copy, Scan, Fax
First Page Out Time	As fast as 6.5 seconds
Copy Resolution	Up to 600 x 600 dpi
First Copy Out Time	As fast as 10 seconds
Fax Speed	33.6 Kbps
Print Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Paper Sizes	Letter, Legal, A4, A5, Executive
Scan Resolution	Up to 4800 x 4800 dpi
Weight	25.1 lbs
Operating System Compatibility	Windows, Mac, Linux
