Xerox WorkCentre 3315

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-49
Parts List 8.3 WorkCentre 3325 Upper DADF
Item Name Part Number
0 Upper DADF
2 Rubber DADF MEA Unit (Separator Pad) 003N01042
3 Pad ETC Spring
4 Idle ADF M Roller
5 Taptype Screw
6 Top DADF Upper Cover
7 Path Sheet
8 Exit ETC Spring
9 SCF M Idle Roller
10 Idle Feed Shaft
11 Lifting Idle Holder
12 Upper DADF Damper
13 Antistatic Brush MEC
14 BT DADF Upper Cover
15 Ground Brush
16 Upper DADF Ground
17 DADF Sensor 2 Harness
18 Paper Empty Sensor
19 Paper Empty Actuator
20 Torsion Doc (CC2-F) Sprint ETC
21 Scan GND CBF Harness
