Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-53
Parts List 9.1 WorkCentre 3315 Scanner and ADF
Item Name Part Number
0 MFA
1 Scanner (See PL 9.2.2)
1.1 Platen
1.2 Hinge (This is 1 hinge. Left and right hinges are the same) 003N01102
1.3 ADF
1.4 Connector Cover
1.5 White Cushion 055N00320
2 Control Panel Assembly
2.1 Control Panel Cover
Outside
Inside (110V)
Inside (220V)
101N01467
101N01461
101N01462
2.2 Function Key
2.3 FAX Key
2.4 Numerical Key
2.5 Start Key
2.6 Power Key
2.7 Power B Key
2.8 Status Lens
2.9 OK Key
2.10 Menu Key
2.11 Stop Key
2.12 LCD Cover
2.13 Control Panel Board 140N63642
2.14 Taptype Screw
3 LCD Display (3315 & 3325) 123N00264
