Xerox WorkCentre 3315 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-55
Parts List 9.2 WorkCentre 3315 Platen
Item Name Part Number
0 Platen 090N00173
1 Upper Platen 090N00171
1.1 Upper Scan Cover
1.2 Shading Sheet
1.3 Double Face Tape
1.4 Double Face Tape
1.5 Platen Glass
1.6 ADF Glass
1.7 Double Face Tape
1.8 Scan Bracket
1.9 Glass Holder IPR
1.10 Glass ADF Sheet
1.11 Upper Scan Ground
1.12 Taptype Screw
2 Lower Platen {Scanner Works} 090N00174
2.1 Lower Scan Cover
2.2 A4 Middle Platen 090N00172
2.3 ADF PBA (ADF Board) 140N63641
2.4 OPE Harness
2.5 Joint ADF Harness
2.6 B Lower Scan Ground
2.7 Taptype Screw
3 Taptype Screw
www MK-Electronic de
