Xerox WorkCentre 3315

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-59
Parts List 10.2 WorkCentre 3325 Platen
Item Name Part Number
0 Platen 090N00178
1 Lower Platen (Complete 3325 Scanner) 090N00176
1.2 Lower Scan Cover
1.3 Ground Connection
1.4 Lower Scan Ground
1.5 Tap-type Screw
1.6 Joint PBA (LCD)
1.8 Joint DADF Harness
1.9 Control Panel Harness
1.10 A4 Middle Platen 090N00177
2 Upper Platen 090N00175
2.2 Upper Scan Cover
2.3 Double Face Tape
2.4 Shading Sheet
2.5 Platen Glass
2.6 Double Face Tape
2.7 ADF Glass
2.8 Double Face Tape
2.9 Scan Bracket
2.10 Upper Scan Ground
2.11 Taptype Screw
2.12 ADF Glass Sheet
2.13 Glass Holder IPR
3 Taptype Screw
