Product Specifications
Operating Systems
Microsoft
®
Windows
®
XP SP3 (32- and 64-bit)
Windows Server 2003 (32- and 64-bit)
Windows Server 2008 and R2 (32- and 64-bit)
Windows Server 2012 and R2
Windows Vista SP2 (32- and 64-bit)
Windows 7 (32- and 64-bit)
Windows 8 (32- and 64-bit)
Windows 8.1 (32- and 64-bit)
Mac OS 10.7, 10.8, 10.9
Linux
®
Redhat
®
Fedora
®
Core 19 x86
Ubuntu
®
13.10 x64
openSUSE
®
13.1 x64
Media Handling
Duplex Automatic Document
Feeder
Capacity: 130 sheets (Single-pass DADF)
Speed: up to 80 images per minute black-and-white and color (simplex) / up to 133 images per minute black-and-white and color (duplex)
Paper Size Sensed: 5.5 x 8.5 in. to 11 x 17 in. / A5 to A3
Weights: 16 lb. bond to 32 lb. bond / 50 gsm to 128 gsm
Bypass Tray Capacity: 100 sheets
Sizes: Custom sizes: 3.5 x 3.9 in. to 12.6 x 19 in. / 89 x 98 mm to 320 x 483 mm
Weights: 16 lb. bond to 110 lb. cover / 55 to 300 gsm
Trays 1 and 2 Capacity: 520 Sheets each
Sizes: Tray 1: Custom sizes: 5.5 x 7.5 in. to 11.7 x 17 in. / 140 x 182 mm to 297 x 432 mm short edge feed (SEF)
Tray 2: Custom sizes: 5.5 x 7.5 in. to 12 x 18 in. / 140 x 182 mm to SRA3 (SEF)
Weights: 16 lb. bond to 140 lb. index / 55 to 256 gsm
High Capacity Tandem Tray
(Total 2,000 sheets)
Capacity: Tray 3: 867 sheets, Tray 4: 1,133 sheets
Sizes: Standard Sizes: 8.5 x 11 in. / A4, JIS B5, Executive (7.25 x 10.5 in.) LEF
Weights: 16 lb. bond to 140 lb. index / 60 to 256 gsm
High Capacity Feeder (HCF)
(Optional)
Capacity: 2000 sheets
Sizes: Standard Sizes: 8.5 x 11 in. / A4, 7.25 x 10.5 in. / B5 LEF
Weights: 16 lb. bond to 140 lb. index / 55 to 256 gsm
Envelope Tray (Optional – Replaces
Tray 1)
Capacity: Up to 60 envelopes
Sizes: #10 Commercial (9.25 x 4.125 in.), Monarch, DL, C5
Custom sizes: 3.9 x 5.8 in. to 6.4 x 9.5 in. / 98 x 148 mm to 162 x 241 mm)
Weights: 20 lb. bond to 24 lb. bond / 75 to 90 gsm
Operating Environment
Required Temperature Range 50° to 82° F (10° to 28° C)
Required Relative Humidity 15% to 85%
Sound Power Levels Operating 7.82 LwAd (B), Standby: 4.45 LwAd (B)
Sound Pressure Levels Operating: 65.7 LpAd (dBA), Standby: 26.7 LpAd (dBA)
Electrical North America
Voltage: 110-127 VAC +/- 10% / Frequency: 50/60 Hz +/- 3%, 20 A
Europe Voltage: 220-240 VAC +/- 10% / Frequency: 50/60 Hz +/- 3%, 10 A
Dimensions
Width Depth Height Weight
Base Configuration 25.2 in. / 640 mm 27.5 in. / 699 mm 45.2 in. / 1,149.2 mm 334.2 lbs. / 151.9 kg
Base Configuration with BR Finisher
51.3 in. / 1,302 mm 27.5 in. / 699 mm 45.2 in. / 1,149.2 mm 430.4 lbs. / 195.6 kg
Base Configuration with BR Booklet
Maker Finisher
56.4 in. / 1,431.4 mm 27.5 in. / 699 mm 45.2 in. / 1,149.2 mm 467.1 lbs. / 212.3 kg
Base Configuration with BR Booklet
Maker Finisher and C Fold / Z Fold
Unit
65.5 in. / 1,664.2 mm 28.6 in. / 726 mm 45.2 in. / 1,149.2 mm 581.7 lbs. / 264.4 kg
Base Configuration with BR Booklet
Maker Finisher, C Fold / Z Fold Unit
and High Capacity Feeder
77.9 in. / 1,978.2 mm 28.6 in. / 726 mm 45.2 in. / 1,149.2 mm 654.5 lbs. / 297.5 kg
Certifications
FCC Class A Compliant (US), ICES Class A Compliant (Canada)
TUV Listed to “UL 60950-1, Second Edition”
TUV Certified to “CSA 22.2 No. 60950-1-07, Second Edition”
CB Certified / CE Marked (IEC 60950-1, Second Edition)
ENERGY STAR
®
Version 2.0
EAC
NOM
Ukraine
Blue Angel
Eco Logo
EPEAT (United States)
GS Mark
To view the latest list of certifications, go to www.xerox.com/OfficeCertifications.
Xerox
®
WorkCentre
®
7970 Evaluator Guide 13
Section 3: Configuration Summary, Product Specifications,
Finishing Options and Supplies and Support Resources
Product Specifications
