Wires connection.
⒈ Black wire: -12V
⒉ Red wire: +12V
⒊ Purple wire : ACC
⒋ Microphone
⒌ Connect relay.
⒍ White wire: connect guard
against theft implement.
⒎ SOS.
⒏ Oil and Power
8
